In the world of electronics, logic controls power.

With over 300 Solid State Relays, Optocouplers, MOSFET and TRIAC Drivers to enable the safe, isolated, and efficient control of the electronics powering your world, Solid State Optronics sits at the intersection of logic and power.

At The Intersection Of Logic And Power

Driven by the passion for technology and the singular goal of creating innovative products for a developing markets, SSO is an industry pioneer in the design and manufacture of miniature Solid State Relays (SSRs) and numerous other optically isolated semiconductor devices.

MOSFET OutputSSRs

AC OutputSSRs

MOSFETDrivers

Optocouplers

TRIACDrivers

IGBTDrivers

SpecialtyProducts

High Temp/Hi RelDevices

MOSFET Output SSRs

MOS Output Solid State Relays (SSRs) are the most reliable, technically advanced logic-to-power interface devices available. Their basic function is to take a low current signal from a microprocessor to control the switching of both AC and DC loads, while providing an isolation barrier between logic and power.

Features
  • Long life, fast and reliable switching
  • Bounce-free switching
  • Optical Input to Output isolation up to 5000Vrms (and beyond)
  • Low Drive Current Options (<1mA)
Applications
  • Telecom/Datacom switching
  • Multiplexers
  • Meter reading systems
  • Data acquisition

AC Output SSRs

AC Output Solid State Relays (SSRs) provide an optically isolated means of switching AC Loads. Activated by the application of a logic level signal, these SCR-based devices tend to be more robust than their MOSFET Output counterparts, typically making them better suited to industrial switching applications wherein a load may connect directly to an AC Line.

Features
  • High blocking voltage (up to 800 V)
  • Switching AC loads without the generation of transients (ZVC devices)
  • High Input to Output Isolation (5000Vrms)
  • Long life / Bounce-free switching
  • and more
Applications
  • Programmable Control
  • Valve control
  • Solenoids and coils
  • Remote switching
  • Home appliances
  • Metering equipment
  • Heating Controls
  • and more

MOSFET Drivers

Also referred to as MOSFET Gate Drivers or Gate Drive Optocouplers, SSO Photo-Voltaic MOSFET Drivers are an optically isolated means of driving discrete MOSFETs. Unlike conventional MOSFET Drivers, Photo-Voltaic MOSFET Drivers require no complex and costly external power supply circuitry to operate.

Features
  • High input to output potential isolation (up to 5kVrms)
  • No need for external power supply
  • Solid State Reliability
  • Input control current (2-20mA)
  • Open Circuit Voltages (6-14V)
  • Short Circuit Currents (3-25uA)
  • and more
Applications
  • MOSFET Driver
  • Programmable Controls
  • Process Controls
  • Instrumentation
  • Telecommunications
  • Discrete SSRs
  • Floating Power Source

Optocouplers

Optocouplers provide a means of optically isolated signal coupling. Whereas SSO's MOSFET and SCR Output SSRs provide integrated switching solutions, our broad line of optocouplers allow for flexibility where completely electronically isolated devices can be coupled discretely to a wide range of load handling components such as Power MOSFETs and Triacs.

Types
  • Transistor Output Optocouplers
  • Linear Optocouplers
  • High Speed Optocouplers
  • Schmitt-Trigger Optocouplers
Applications
  • Office equipment including: Registers, Copiers, Fax Machines, and Laser Printers
  • Home appliances, including; Microwave Ovens, Washers & Dryers, Refrigerator, Air conditioner, etc.
  • and more

TRIAC Drivers

Also known as a Phototriac Coupler, a TRIAC Driver is a specific type of optocoupler that is used exclusively to provide an optically isolated gate drive current to a TRIAC. This allows designers greater flexibility in selecting the gate drive current and isolation value desired separately from the TRIAC required.

Features
  • High input to output potential isolation (5 kVrms and beyond)
  • Low input control current (as low as 2.5mA)
  • Variable load voltages (400V to 800V)
  • Random Phase and Zero Volt Switching
Applications
  • Motor Control
  • Motor Starters
  • Dimmer Circuits (random phase devices)
  • Solenoid/Valve controls
  • Lighting controls
  • Static power switches
  • Temperature controls
  • Solid State Relays

IGBT Drivers

IGBTs are commonly used in power electronic applications such as Uninterruptible Power Supplies (UPS), Solar inverters, Inductive heating, Motor Control, HF Welding and other PWM applications that require high switching speeds.

Features
  • High Common Mode Rejection: 10 - 25kV/uS at VCM = 1500V
  • Under Voltage Lockout Protection (UVLO) with Hysteresis
  • Broad Temperature Performance Range (-40°C to 100°C)
  • Maximum Peak Output Currents of 0.6 – 2.5A
  • and more
Applications
  • IGBT / MOSFET Gate Drives
  • AC & Brushless DC Motor Drives
  • Industrial Inverters
  • Uninterruptable Power Supplies (UPS)
  • Switch Mode Power Supplies

High-Temp/High Rel Drivers

As an innovative company, we work closely with our Customers to understand and respond to your requirements. In addition to custom products, SSO also offers Hi-Temp and Hi-Rel versions of many of our standard products to address the demands of your applications.

Features
  • Guaranteed operation up to 105ºC and beyond
  • Guaranteed operation to -40ºC and lower
  • Full Parametric testing at room temp, elevated temp, or over a temperature sweep
  • and more
Full Product Traceability
  • Full assembly traceability by manufacturing lot
  • Archive samples per each manufacturing lot
  • Full materials traceability by material lot
  • and more

Specialty

Specialty Products include a wide range of devices that are either hybrid in nature, custom in design or application or otherwise do not fit in conventionally defined product families.

Features
  • Optically isolated coupling to broad range of defined output types
  • Low input control current
  • Optically isolated function integration in a single package
  • Consolidated circuit functions into a single device, freeing up valuable board space and reducing component count
Applications
  • Telecom/Datacom switching
  • Medical equipment
  • I/O Sub-Systems
  • Robotics
  • Aerospace
  • Home/Safety security systems
  • Industrial Controls

Latest at
SSO

Product Focus and Industry News

SSO has announced the availability of a new miniature AC Output Solid State Relay with a high blocking voltage of 800V.

Latest from Our Lab

A global electronics company based in Western Europe approached us with a technical challenge. SSO delivered.

Application Notes

In a MOSFET based relay, both AC and DC signals can be switched. The output utilizes two n-channel type MOSFETs. When controlling an AC load, one of the MOSFETs is used to switch the positive phase of the AC cycle while the other is used to switch the negative phase.

Product Focus and Industry News

SSO has added a 1 Form B version of its new miniature DC Output Solid State Relay with high continuous load current rating of up to 3.4A.

Over 40 Years
of Industry Experience.

Are you looking for devices that can:

  • Handle high load voltages of 1kV or more?
  • Offer higher Isolation voltages (5kV, 10kV, or more)?
  • Provide fast switching of high frequency loads?
